| 型號 |
料筒 容積 |
裝料 容積 |
最大 裝料量 |
搖動、轉動次數 |
電機 總功率 |
外形尺寸 (長×寬×高) |
料筒 重量 |
重量 (kg) |
| EYH-60 | 60 | 30 | 20 | 50 | 0.4 | 700×730×1100(mm) | 15 | 115 |
| EYH-150 | 150 | 75 | 50 | 37 | 1.15 | 800×1050×1450(mm) | 50 | 190 |
| EYH-300 | 300 | 150 | 100 | 30 | 1.15 | 900×1350×1550(mm) | 60 | 340 |
| EYH-600 | 600 | 300 | 200 | 23.6 | 3 | 1170×1640×2050(mm) | 140 | 1150 |
| EYH-800 | 800 | 400 | 280 | 19.8 | 3 | 1320×1950×2150(mm) | 200 | 1600 |
| EYH-1000 | 1000 | 500 | 350 | 19.8 | 3 | 1360×2040×2300(mm) | 240 | 1700 |
| EYH-1500 | 1500 | 750 | 520 | 16.2 | 4.4 | 1580×2400×2550(mm) | 320 | 2000 |
| EYH-2000 | 2000 | 1000 | 700 | 16.2 | 7.4 | 1740×2600×2770(mm) | 430 | 2600 |
| EYH-3000 | 3000 | 1500 | 1050 | 13.8 | 11 | 1800×2900×2950(mm) | 620 | 3500 |
| EYH-4000 | 4000 | 2000 | 1400 | 12.8 | 13 | 1970×3300×3300(mm) | 700 | 4100 |
| EYH-6000 | 6000 | 3000 | 2100 | 11.2 | 18.5 | 2300×2900×3800(mm) | 1100 | 6100 |
| EYH-8000 | 8000 | 4000 | 2800 | 10.4 | 22 | 2540×4100×4050(mm) | 1450 | 7900 |
| EYH-10000 | 10000 | 5000 | 3500 | 9 | 30 | 2900×4500×4400(mm) | 1650 | 9500 |
